Olimex Lime A64

Suitable for testing (WIP)

beta

Armbian Xenial
desktop nightly legacy kernel 3.10.y

Automated build.

Direct download

Kernel Issues

beta

Armbian Stretch
nightly mainline kernel 4.14.y

Automated build.

Direct download

Kernel Issues

Check other download options

Important: Some devices suffer from a Gbit Ethernet issue related to the GbE PHY leading to a severe amount of packet losses which might render Ethernet unuseable. It’s confirmed as a hardware issue and if you’re affected or not can be simply checked by testing network throughput with iperf3. Against another GbE capable device, you should exceed 900 Mbits/sec with Armbian (only 800 Mbits/sec in RX direction when not using Xenial due to iperf3 being single-threaded in both directions then and bottlenecked by CPU). If you see low throughput and high retransmit counts then a workaround is to switch to Fast Ethernet only by adding ethtool -s eth0 speed 100 duplex full to /etc/rc.local

Specifications

1000tx 1wire 2GB 4 core 64bit CAN battery bluetooth docker eMMC i2c i2s spi wifi Allwinner A64

* Specifications differ from hardware revision, model and software support level

FAQs

WHICH IMAGE SHOULD I DOWNLOAD?

HOW TO START?

Preparation Make sure you have a good & reliable SD card and a proper power supply. Archives can be uncompressed with 7-Zip on Windows, Keka on OS X and 7z on Linux (apt-get install p7zip-full). RAW images can be written with Etcher (all OS). Boot Insert the SD card into the slot, connect a cable to your network if possible or a display and power your board. (First) boot (with DHCP) takes up to 35 seconds with a class 10 SD Card. Login Log in as: root Password: 1234. Then you are prompted to change this password (US-Keyboard setting). When done, you are asked to create a normal user-account for your everyday tasks.

WHERE TO GET SUPPORT?

SUPPORTED devices are tested and they work apart from known issues and missing features. Support is provided as far as possible (in general there is no support for 3rd party hardware like DVB tuners and software like Kodi). Please check the documentation and existing forum posts before posting a question. SUITABLE FOR TESTING (WIP) are devices which we’re currently working on but they are not ready! These images are suitable for developers and experienced users. They are not very well tested but they might work without any problems. Your help to improve this situation is greatly appreciated. SUPPORT ENDED (EOS) status are devices which used to be supported in the past. Reasons for moving to this section:

no active software development (mainline u-boot and kernel)
no support from the vendor (hardware samples, documentation, software packages)
never was sold, only samples in small quantities were available
hardware design flaws don’t allow using these devices without stability issues

Support status:

images are stable but we don’t test updating,
images are provided with no support,
most images have frozen kernel and u-boot packages to prevent their upgrades.

NO OFFICIAL SUPPORT (CSC) are devices which are supported by the 3rd party. We usually don't have hardware samples nor conduct any tests but they might work. There is no support whatsoever.
