Additional information
Details about the MKS Klipad50 board and Sovol’s KlipperScreen:
- Hardware details
- Implementation status in Armbian images
Github project with issue tracker, discussions and custom images:
Flashing instructions:
More information:
https://github.com/armbian/build/pull/7553
- Images for non LTS version can be downloaded here
- There is currently a known issue that may affect this board on some IPv4 only networks. Symptoms are variable, from intermittent drop-outs and slow-downs to total loss of one NIC or total loss of networking. The issue can be completely eliminated by disabling IPv6. Don’t try to do this through armbian-config as this method does not work. IPv6 must be disabled by adding a line
extraargs="ipv6.disable=1"to /boot/armbianEnv.txt - Device tree overlays to enable uart1 and i2c0 are available in Armbian 23.02.
- There may be a known issue that could affect this board on some IPv4 only networks. Symptoms are variable, from intermittent drop-outs and slow-downs to total loss of one NIC or total loss of networking. The issue can be completely eliminated by disabling IPv6. Don’t try to do this through armbian-config this method does not work. IPv6 must be disabled by adding a line
extraargs="ipv6.disable=1"to /boot/armbianEnv.txt
In case of troubles booting, read this topic.
- USB-C power Input Only
- Login console is enabled also on mUSB connector
- Known problem: reboot sometimes doesn’t bring the device back.
- Network devices are not managed by Network manager. Configure via /etc/network/interfaces
- UART is accessible on pin 6 (GND),8 (TX) and 10 (RX) and with unusual speed: 1500000
- Video and 3D acceleration addon
- Clocking to maximum safe CPU speed (1.51Ghz) is possible this way:
sed -i "s/MAX_SPEED=.*/MAX_SPEED=1510000/" /etc/default/cpufrequtils service cpufrequtils restart
Make sure to install large heatsink!
